pre30 seconds 0% stimuli pattern, minimum luminance level of 0.001fL....the lowest my AEMC
813 can go). Fullscreen white contrast ratio measured 21,300:1 (21.3fL peak white, 0.001fL
video black). ANSI came in at 14,600:1.
Grayscale
Grayscale averaged 6347 from 10100% stimuli. Although this grayscale isn't true D65, I found it
very pleasing to the eye and was hard pressed to see the slightly "redder" tone on regular
content. Any RGB Service Menu tweaks on this PDP will yield an incremental improvement at
best.
IRE
Measurement

10
6138
20
6340
30
6356
40
6389
50
6370
60
6420
70
6347
80
6371
90
6362
100
6385
Color Points
Just like its predecessor, the PDP6020FD's user menu does not house any controls that can be
used to properly calibrate the colors. On top of that, Pioneer has again chosen to hardcode the
6020FD with a wider color gamut (Colorspace 1) which exceeds the reference HD Rec. 709
colorspace. The actual color points are remarkably similar to the 6010FD, with oversaturated
green and red primaries, greener yellow, and a redder magenta:
